Pezzimenti Tunnelbore specialises in microtunnelling – the drilling of highly accurate, laser-guided bores ranging in diameter from 325mm to 3000mm in ground ranging from sandy clay to basalt in lengths up to and beyond 300m. Microtunnelling has become an integral part of installing gravity flow sewers and stormwater in urban areas.

Innovation In-House

Pezzimenti Tunnelbore Innovation in-House

All equipment used by Pezzimenti Tunnelbore is designed and manufactured in the Melbourne Workshop, giving the flexibility to design machinery to achieve project-specific solutions.

Unsurpassed Experience

Pezzimenti Tunnelbore Unsurpassed Experience

Since inventing vacuum spoil extraction in 1986, the Pezzimenti Microtunnelling System has completed more than three times the number of bores of any other alternative in Australia.

Environmentally Safe

Pezzimenti Tunnelbore Microtunnelling Environmentally Friendly

Unlike other pipe installation techniques, our system leaves the surface undisturbed. Critical surface areas including areas of Aboriginal significance and natural water courses all remain untouched, ensuring the protection and preservation of their value.

Microtunnelling Ground Conditions Capability

Ground

Detatchable cutters and a modular system means Pezzimenti can operate in very soft to very hard rock

Microtunneling Length Icon

Length

Single drives up to 260m and lengths up to 440m, using intercept bore method.

Microtunnelling Diameter Icon

Diameter

The system that can microtunnel diameters ranging from 300mm up to 3000mm.

Microtunnelling Pipes Icon

Pipes

Any pipe that is available in the Australian market can be installed with this system.

Microtunnelling Accuracy Icon

Accuracy

The laser guided system achieves as standard: +/-10mm at distances up to 150m and +/-40mm at 200m.

Microtunnelling Versatility Icon

Versatility

The modular system means we can achieve setup in very tight or expansive sites.

Feature Project – Riley’s Creek

RIleys Creek Feature Project

The Rileys Creek Carrier was designed as a trunk main to service properties either side of Camden Lakeside Golf Club. The carrier had to be constructed with minimal disruption to the golf course facilities and players. 11 Microtunnels were completed totalling 1049m.

Recent Projects

Macquarie Park Pezzimenti Tunnelbore Feature Image

Macquarie Park

Leppington Pezzimenti Tunnelbore Microtunnelling Feature

Leppington

Rileys Creek Pezzimenti Microtunnelling Feature Image

Rileys Creek

Menagale Pezzimenti Tunnelbore Microtunnelling Feature

Menangle

Eastern Creek Microtunnelling beneath M7 Highway feature

Eastern Creek

Mount Druitt Pezzimenti TUnnelbore Microtunnelling Feature

Mount Druitt

Pezzimenti Oran Park Microtunneling Intercept Bore

Oran Park

Pezzimenti Tunnelbore Microtunnelling Project Downer ACT Feature

Downer ACT

East St Clair

East St Clair

News and Articles

Emerald hills Intercept Bore Feature Image

Video: Emerald Hills

| Video | No Comments
Pezzimenti Tunnelbore complete a 440m Intercept bore in Emerald Hills, the longest microtunnel at 530mm diameter in Australia. In this video, Scott Wells from Pezzimenti Tunnelbore teams up with David...
1000 Microtunnels for Pezzimenti Tunnelbore Feature Image

The 1000th Microtunnel

| Uncategorized | No Comments

Pezzimenti Tunnelbore Completes 1000 Microtunnels, based in Sydney, from 1994 to 2016. Jim Shooter, Pezzimenti Tunnelbore’s NSW Manager, talks through the milestone.

Pezzimenti Tunnelbore Pipejacking Capability Feature

Video: Pipejacking Capability

| Uncategorized | No Comments

Pipejacking Capability and overcoming High Risk Ground, Length and Grade Conditions.

ASTT Special Interest Group Design Guidelines for Sewers

ASTT Special Interest Group – Design Guidelines for Sewers

| Uncategorized | No Comments

A groundbreaking Special Interest Group (SIG) has been established to formulate Microtunnelling Design Guidelines for Sewers.

PRESENTATIONS FOR DESIGNERS

Our 1 hr presentation will educate your team on current microtunnelling capability for more efficient, practical and cost-effective project solutions. Book today.


Contact us to Book Presentation

Pezzimenti Presentation Slide

Partner with Microtunneling Expertise

Pezzimenti Tunnelbore works with our developers, contractors and designers to create quality microtunneling solutions whatever the project requirements.
